UNV NSW3000-8T2GT-POE-IN 8-Port Cloud-Managed PoE+ Switch

Uniview

8-Port Cloud-Managed PoE+ Switch

Model: NSW3000-8T2GT-POE-IN

$189.00 $229.00

In stock

Apply for dealer pricing For approved dealers. Pricing and terms vary by product and quantity.

At a glance

  • Built-in PoE: 8 × 10/100Mbps PoE RJ45 Ports
  • Switching Capacity: 5.6Gbps
  • Power Supply: AC 100–240V, 50/60Hz
  • Dimensions: 169 × 132 × 40mm
Warranty Limited manufacturer warranty: 3 years Warranty help
Secure CheckoutProtected payment processing
U.S. SupportProfessional product guidance
Fast FulfillmentU.S. warehouse order processing
30-Day Eligible ReturnsUnused items with approved RMA

Need help choosing? (856) 317-0600

Overview

The UNV NSW3000-8T2GT-POE-IN provides eight PoE+ camera ports and two Gigabit uplinks in a fanless chassis. It is a practical network hub for a compact IP camera system.

  • 8 × 10/100Mbps PoE ports
  • 2 Gigabit RJ45 uplinks
  • 120W shared PoE budget
  • Cloud, web and supported app management

Power distribution

Each PoE port supplies up to 30W, within the total 120W budget. Include the cameras’ maximum night-mode consumption when allocating power.

Long cable runs

Extended transmission can reach approximately 250m at a reduced rate of up to 10Mbps. That mode trades bandwidth for distance, so check each camera’s configured bitrate.

Specifications

Model NSW3000-8T2GT-POE-IN
Product Type Cloud-Managed Ethernet PoE Switch
PoE Ports 8 × 10/100Mbps PoE RJ45 Ports
Uplink Ports 2 × 10/100/1000Mbps Gigabit RJ45 Ports
Network Standards IEEE 802.3, IEEE 802.3u, IEEE 802.3az, IEEE 802.3x, IEEE 802.3af and IEEE 802.3at
Switching Capacity 5.6Gbps
Forwarding Performance 4.17Mpps
Packet Buffer 2 Mbit
MAC Address Table 4K
PoE Standard IEEE 802.3af / IEEE 802.3at
Maximum PoE Budget 120W Total
Maximum PoE Per Port Up to 30W
PoE Mode Mode A: Pins 1, 2, 3 and 6; Mode B: Pins 4, 5, 7 and 8
Priority Ports Ports 1–2
Extended Transmission Up to approximately 250 meters at a reduced rate of up to 10Mbps
VLAN Access and trunk modes; up to 32 VLANs with IDs from 1–4094
Network Features Link aggregation, loop detection, port isolation, port mirroring, rate limiting, flow statistics and broadcast storm control
Management Supported Uniview Software, Cloud Management, Mobile Application and Web Interface
Power Supply AC 100–240V, 50/60Hz
Maximum Power Consumption 130W
Cooling Fanless
Dimensions 169 × 132 × 40mm
Weight Approximately 0.67kg
Operating Temperature 0°C to 45°C / 32°F to 113°F
Operating Humidity 5% to 90% RH, Non-Condensing
Compliance NDAA Compliant

Compatibility

Supports IEEE 802.3af/at devices. High-power cameras that exceed a port’s rating require a different power source.

Need help matching this product to your project? Ask NSI

Specifications

Compatibility & accessories

Downloads & support

Find model-specific documentation and available software in Uniview’s Download Center.

Official Uniview downloads
