UNV XVR301-08Q4 8-Channel 1 HDD Hybrid DVR

SKU: XVR301-08Q4

$279.00 $339.00
Secure CheckoutProtected payment processing
U.S. SupportProfessional product guidance
Fast ShippingU.S. warehouse fulfillment
Easy RMA SupportStreamlined assistance when needed
Need compatibility help? Call (856) 317-0600 for professional assistance.
Overview Resources & Support Compatibility Solution Builder Specifications
Product overview

Reliable Video Recording

Built for dependable video recording, AI analytics, and scalable surveillance deployments. Features vary by model, firmware, storage configuration, and connected devices.

Professional Quality

Designed for demanding surveillance and networking environments.

System Compatibility

Use the compatibility tools below to select supported components.

Technical Support

Get assistance with configuration, installation and product selection.

Secure Purchasing

U.S.-based fulfillment and protected checkout.

Product assistance

Need Assistance?

Documentation, system compatibility tools, shipping information, and direct support from NSI Security.

Shipping InformationU.S. fulfillment

Processing times, delivery estimates, signature requirements, and shipping limitations vary by order and destination.

View Shipping Policy →
DocumentationBy request

Review current datasheets, manuals, firmware notes, and manufacturer documentation before ordering or installation.

Request Documentation →
Technical SupportNSI assistance

Get product selection, compatibility, configuration, and basic troubleshooting assistance from NSI Security.

Contact Support →
Verified System ComponentsProduct-specific compatibility

Review product-specific cameras, recorders, cable, networking, storage, power, and accessories assigned to work with this item.

View Components →
RMA RequestAfter-purchase assistance

Request return authorization, repair evaluation, or replacement assistance for an eligible order.

Start RMA Request →
Contact Our TeamSales and product questions

Contact NSI Security for product selection, availability, compatibility, and order assistance.

Contact NSI Security →
System compatibility

Verified System Components

Product-specific components selected for a more confident system configuration. Only populated categories are displayed.

One-click system configuration

Build Your Complete Solution

Select the components you need and add the complete configuration to your cart.

Storage

Product information

Product Details & Technical Specifications

8-Channel 5-in-1 Hybrid DVR / XVR

UNV XVR301-08Q4 8-Channel 1 HDD Hybrid Digital Video Recorder

The UNV XVR301-08Q4 is an 8-channel hybrid DVR / XVR designed for analog camera upgrades and mixed coax + IP surveillance systems. It supports TVI, AHD, CVI, CVBS, and IP camera access, with 8 BNC inputs, up to 12 IP channels in IP-only mode, H.265 / H.264 compression, HDMI output up to 4K, VGA output, ONVIF compatibility, two-way audio support, Ultra Motion Detection, Smart Intrusion Prevention, and 1 SATA HDD bay for recording storage.

8CH
BNC Input
12CH
Max IP Mode
1 HDD
SATA Bay
4K
HDMI Output

Important HDD Notice

This DVR does not include a hard drive unless specifically selected or stated on the order. HDD storage must be purchased separately or added as an option. Recording days will depend on camera count, resolution, bitrate, frame rate, recording schedule, motion settings, scene activity, and hard drive size.

Hybrid DVR Compatibility Notice

This is a hybrid DVR/XVR for coax and supported IP camera systems. It supports TVI, AHD, CVI, CVBS, and IP camera access. Compatibility may depend on camera signal format, camera resolution, firmware version, coax cable quality, power supply, and DVR settings. Please confirm your existing camera type before ordering.

Upgrade Existing Coax Systems With Hybrid IP Expansion

The XVR301-08Q4 is ideal for replacing older 8-channel analog DVRs while keeping existing coax cable runs. It gives installers flexibility to support analog cameras, add supported IP cameras, improve compression, use modern remote viewing options, and plan storage with one internal HDD bay.

Key Features

🎥

8-Channel BNC Input

Supports 8 analog camera inputs for coax-based surveillance systems.

🔁

5-in-1 Camera Support

Supports TVI, AHD, CVI, CVBS, and IP camera access for flexible analog replacement projects.

📹

Analog Camera Support

Supports TVI / AHD up to 8MP @ 12fps and CVI up to 8MP @ 15fps within supported DVR limits.

🌐

IP Camera Expansion

Supports 4 IP channels together with analog cameras, or up to 12 IP channels when used in IP-only mode.

💾

1 SATA HDD Bay

One internal hard drive bay supports local video recording storage planning.

🖥️

4K HDMI Output

HDMI output supports up to 4K resolution for local live view and playback display.

🧠

Smart Detection Support

Supports Ultra Motion Detection and Smart Intrusion Prevention features on supported channels.

Feature Overview

✓ 8-channel BNC analog video input
✓ 4-channel IP video input with analog cameras
✓ Up to 12-channel IP-only mode
✓ TVI / AHD / CVI / CVBS / IP adaptive access
✓ TVI / AHD support up to 8MP @ 12fps
✓ CVI support up to 8MP @ 15fps
✓ Main stream recording up to 8MP Lite @ 8fps
✓ Extra stream recording: D1 @ 30fps
✓ ONVIF compatible IP camera support
✓ H.265 / H.264 video compression
✓ IP camera resolution up to 4K
✓ 1 SATA HDD interface
✓ HDD sold separately unless selected
✓ HDMI output up to 4K, 3840 × 2160
✓ VGA output up to 1920 × 1080
✓ Two-way audio support
✓ Audio over coax support with compatible cameras
✓ Up to 8-channel Ultra Motion Detection
✓ Up to 4-channel Smart Intrusion Prevention
✓ 40Mbps bandwidth support
✓ RS485 support

Analog Camera Support & Recording Limits

The UNV XVR301-08Q4 supports multiple HD analog camera formats, but the connected camera resolution and frame rate must stay within the DVR supported limits. This is important when upgrading older coax systems or mixing different analog camera resolutions.

TVI / AHD Analog Camera Support 8MP @ 12fps, channels 1–8
5MP @ 20fps
4MP @ 30fps
3MP @ 30fps, channels 1–8
1080P @ 30fps
720P @ 60fps
CVI Analog Camera Support 8MP @ 15fps, channels 1–8
4MP @ 30fps
1080P @ 30fps
720P @ 60fps
Main Stream Recording Encoding 8MP Lite @ 8fps, channels 1–8
5MP Lite @ 12fps
4MP Lite @ 15fps
3MP @ 15fps, channels 1–8
2MP @ 15fps
720P @ 30fps
Extra Stream Recording Encoding D1 @ 30fps

Important Live Display Notice

For correct live display, the resolution and FPS combination of the connected analog cameras must be equal to or lower than the specifications listed above. The connected camera resolution and FPS should not exceed the DVR’s supported specification limits.

Best Applications

Analog DVR Upgrades
Coax Camera Systems
Retail Stores
Small Businesses
Restaurants
Mixed Analog + IP

Product Highlights

Model XVR301-08Q4
Recorder Type 8-Channel Hybrid Digital Video Recorder / XVR
Analog Video Input 8-Channel BNC Input
Camera Support TVI / AHD / CVI / CVBS / IP Cameras
TVI / AHD Support 8MP @ 12fps, 5MP @ 20fps, 4MP @ 30fps, 3MP @ 30fps, 1080P @ 30fps, 720P @ 60fps
CVI Support 8MP @ 15fps, 4MP @ 30fps, 1080P @ 30fps, 720P @ 60fps
Main Stream Recording 8MP Lite @ 8fps, 5MP Lite @ 12fps, 4MP Lite @ 15fps, 3MP @ 15fps, 2MP @ 15fps, 720P @ 30fps
Extra Stream Recording D1 @ 30fps
IP Video Input 4 IP Channels with Analog Cameras / Up to 12 IP Channels in IP-Only Mode
HDD Bay 1 SATA HDD Interface
HDD Included No — HDD Sold Separately Unless Selected or Stated
Video Compression H.265 / H.264
Video Output HDMI up to 4K, VGA up to 1080P
IP Camera Compatibility ONVIF Compatible
Bandwidth 40Mbps Supported
Smart Features Ultra Motion Detection and Smart Intrusion Prevention Support

Installation Tip

Before replacing an existing DVR, confirm the current camera signal format, camera resolution, camera FPS, coax cable condition, power supply voltage, audio wiring, monitor output, HDD storage requirement, and remote viewing network setup. For mixed analog and IP systems, also confirm IP camera bandwidth, ONVIF compatibility, and network design.

Note: Specifications are subject to change without notice. Channel capacity, camera signal compatibility, analog resolution support, analog FPS support, live display behavior, IP camera compatibility, recording resolution, HDD support, storage performance, audio-over-coax behavior, video output behavior, remote viewing performance, coax transmission distance, decoding performance, smart detection features, and overall system performance may vary depending on firmware version, camera model, coax cable quality, power supply, hard drive model, network setup, bitrate settings, recording schedule, system configuration, and installation environment. Please always double-check the manufacturer’s official specifications for the most accurate and up-to-date product information before ordering.

Important product information: Specifications are subject to change without notice. Features, storage support, audio functions, image performance, PoE behavior, compatibility and overall system performance may vary depending on firmware, recorder model, installation environment, network setup and system configuration. NVRs do not include hard drives unless explicitly stated.
