UNV IPC6315LFW-AX5C-VG1 | NSI Premium V2
ColorHunter Tri-Guard Mini PTZ

UNV 5MP 5X ColorHunter Tri-Guard Dual-Light Network PTZ Camera

IPC6315LFW-AX5C-VG1

Monitor wide areas with detailed 5MP video, 5X optical zoom, human auto tracking, smart intrusion prevention, dual-light illumination, built-in two-way audio, 512GB MicroSD support, PoE+ and IP66 outdoor protection.

5MP Resolution5X Optical ZoomHuman Auto TrackingDual LightTwo-Way AudioPoE+
5MP2880 × 1620 at up to 30 FPS
5X Zoom2.7–13.5mm motorized lens
Auto TrackingHuman-target tracking support
IP66Outdoor weather protection
Why you’ll love it

Flexible Coverage with Active Deterrence

A compact PTZ solution for entrances, parking areas, storefronts, warehouses, apartment properties and other locations that need adjustable viewing, zoom, tracking and two-way communication.

5MP Video at Up to 30 FPS

Captures detailed 2880 × 1620 video with smooth motion performance.

5X Optical Zoom

The 2.7–13.5mm lens moves from a wide overview to a tighter view without relying only on digital enlargement.

Human Auto Tracking

Supports automatic tracking with human-target filtering within the camera’s supported PTZ range.

ColorHunter Tri-Guard

Combines low-light imaging, smart intrusion prevention and active deterrence.

Smart Dual-Light Illumination

Provides IR up to 164 feet and warm light up to 49 feet under suitable conditions.

Built-In Mic and Speaker

Supports environmental audio, two-way communication and audible deterrence through compatible systems.

120dB True WDR

Balances bright and dark portions of strongly backlit scenes.

MicroSD Edge Recording

Supports compatible MicroSD cards up to 512GB.

Smarter Nighttime Security

Tri-Guard combines intelligent target filtering, active warning functions and dual-light illumination to improve event verification and discourage unwanted activity.

Infrared MonitoringDiscreet black-and-white monitoring up to approximately 50 meters.
Warm-Light ColorVisible illumination supports color evidence up to approximately 15 meters.
Human and Vehicle FilteringHelps reduce false alarms from irrelevant motion.
Audible DeterrenceBuilt-in speaker supports warning sounds and two-way talk.
Efficient CompressionUltra 265 and H.265 reduce storage and bandwidth demand.
Flexible RecordingRecord to compatible NVR, NAS or onboard MicroSD.
Intelligent event detection

AI and Security Functions

Human Auto Tracking
Human Classification
Vehicle Classification
Cross-Line Detection
Intrusion Detection
Motion Detection
Tampering Alarm
Audio Detection
Recommended applications

Perfect For

Retail StoresEntrances and exterior walkways.
Office BuildingsParking areas and approaches.
WarehousesLoading docks and yard areas.
Parking AreasVehicles and pedestrians.
SchoolsExterior entries and common areas.
ResidentialDriveways and yards.
EntrancesTwo-way communication and warning.
Apartment PropertiesCourtyards and shared entrances.
Technical overview

Product Highlights

Camera Type 5MP 5X ColorHunter Tri-Guard dual-light network PTZ camera
Image Sensor 1/2.7-inch CMOS
Maximum Resolution 2880 × 1620
Main Stream Up to 5MP at 30 fps
Sub Stream Up to 720p at 30 fps
Lens 2.7–13.5mm motorized varifocal, F1.6
Optical Zoom 5X
Field of View H: 106.91°–33.55°; V: 56.45°–18.99°; D: 123.1°–42.1°
Minimum Illumination Color: 0.005 lux; 0 lux with IR
WDR 120dB
Night Illumination IR up to 164 ft; warm light up to 49 ft
Compression Ultra 265, H.265, H.264, MJPEG
Auto Tracking Human-target filtering supported
Smart Intrusion Prevention Cross-line and intrusion detection with human/vehicle classification and false-alarm filtering
Audio Built-in microphone and speaker; two-way audio; 1 audio input / 1 output
Alarm I/O 1 input / 1 output
Edge Storage MicroSD up to 512GB
Integration ONVIF Profiles S, G, T and M; SDK; API
Presets Up to 1024
Patrols 16 patrols, up to 64 presets each
Pan Range 0° to 345°
Tilt Range -10° to 100°
Power 12V DC or PoE+ (IEEE 802.3at)
Power Consumption Up to 18W
Protection IP66
Operating Temperature -22°F to 140°F (-30°C to 60°C)
Dimensions 133 × 185 × 286 mm
Weight Approx. 1.74 lb (788 g)

Recorder and Feature Compatibility Notice

Auto tracking, smart intrusion prevention, classification, two-way audio, active deterrence, alarm I/O, MicroSD recording and ONVIF functions may vary depending on recorder model, firmware, VMS, network configuration and settings.

PTZ Coverage Notice

This model has a 0°–345° pan range and is not a continuous 360° endless-rotation PTZ. Confirm mounting position and blind-zone placement before installation.

Professional Installation Tip

Mount the camera where its 345° pan range covers the most important approach paths. Keep reflective surfaces outside the IR and warm-light path. Use a compatible bracket, provide sufficient PoE+ power, and test zoom, presets, tracking, audio and nighttime modes before completing installation.
