UNV IPC3614SR-ADF28KMC-DL-H 4MP NDAA Dual Light Eyeball Camera
In Stock

Uniview

UNV IPC3614SR-ADF28KMC-DL-H 4MP NDAA Dual Light Eyeball Camera

SKU: IPC3614SR-ADF28KMC-DL-H

$329.00
Secure CheckoutProtected payment processing
U.S. SupportProfessional product guidance
Fast ShippingU.S. warehouse fulfillment
Easy RMA SupportStreamlined assistance when needed
Need compatibility help? Call (856) 317-0600 for professional assistance.
Overview Resources & Support Compatibility Solution Builder Specifications
Product overview

Reliable Security Performance

Designed to deliver dependable video surveillance with features and performance that vary by model, firmware, environment, and system configuration.

Professional Quality

Designed for demanding surveillance and networking environments.

System Compatibility

Use the compatibility tools below to select supported components.

Technical Support

Get assistance with configuration, installation and product selection.

Secure Purchasing

U.S.-based fulfillment and protected checkout.

Product assistance

Need Assistance?

Documentation, system compatibility tools, shipping information, and direct support from NSI Security.

Shipping InformationU.S. fulfillment

Processing times, delivery estimates, signature requirements, and shipping limitations vary by order and destination.

View Shipping Policy →
DocumentationBy request

Review current datasheets, manuals, firmware notes, and manufacturer documentation before ordering or installation.

Request Documentation →
Technical SupportNSI assistance

Get product selection, compatibility, configuration, and basic troubleshooting assistance from NSI Security.

Contact Support →
Verified System ComponentsProduct-specific compatibility

Review product-specific cameras, recorders, cable, networking, storage, power, and accessories assigned to work with this item.

View Components →
RMA RequestAfter-purchase assistance

Request return authorization, repair evaluation, or replacement assistance for an eligible order.

Start RMA Request →
Contact Our TeamSales and product questions

Contact NSI Security for product selection, availability, compatibility, and order assistance.

Contact NSI Security →
System compatibility

Verified System Components

Product-specific components selected for a more confident system configuration. Only populated categories are displayed.

One-click system configuration

Build Your Complete Solution

Select the components you need and add the complete configuration to your cart.

Mounting & Accessories

Compatible Recorders

PoE Switches

Product information

Product Details & Technical Specifications

NDAA Compliant 4MP ColorHunter Dual-Light Eyeball Network Camera

UNV IPC3614SR-ADF28KMC-DL-H 4MP ColorHunter Dual-Light Eyeball Network Camera

The UNV IPC3614SR-ADF28KMC-DL-H is a 4MP NDAA-compliant dual-light eyeball IP camera designed for indoor and outdoor security applications. It features a 1/3.0" CMOS sensor, 2.8mm fixed lens, ColorHunter low-light imaging, 120dB true WDR, built-in microphone, built-in speaker, Smart IR, warm light illumination, MicroSD card support, PoE power, ONVIF integration support, and IP67 weather protection.

4MP
HD Image
NDAA
Compliant
Dual Light
IR + Warm Light
120dB
True WDR
IP67
Outdoor Rated

Dual-Light Security with ColorHunter Imaging

The IPC3614SR-ADF28KMC-DL-H is designed for customers who want flexible night monitoring. It supports both IR and warm light illumination, helping the camera adapt to different environments while delivering strong color and detail in low-light scenes.

Key Features

📷

4MP HD Image

Provides clear 4MP video for everyday commercial and professional surveillance applications.

🛡️

NDAA Compliant

Suitable for projects requiring NDAA-compliant security equipment when verified with current manufacturer documentation.

🌙✨

ColorHunter Imaging

ColorHunter helps provide improved color detail in low-light scenes with warm light support.

💡

Dual-Light Illumination

Supports both Smart IR and warm light illumination up to 30m / 98.4ft.

🔆

120dB True WDR

Helps balance bright and dark areas for clearer images in challenging lighting conditions.

🎙️

Built-In Mic & Speaker

Built-in microphone and speaker support audio features when used with compatible recorder, settings, and local regulations.

🔗

ONVIF Integration Support

Supports third-party integration through ONVIF profiles, depending on recorder compatibility and firmware support.

🌧️

IP67 Outdoor Protection

Weather-rated metal housing supports outdoor installation when properly mounted and sealed.

Feature Overview

✓ NDAA compliant / NDAA supported security camera
✓ 4MP ColorHunter dual-light eyeball network camera
✓ 1/3.0" CMOS image sensor
✓ 2.8mm fixed lens
✓ 97.0° horizontal field of view
✓ ColorHunter low-light color imaging
✓ 120dB true WDR
✓ Smart IR up to 30m / 98.4ft
✓ Warm light up to 30m / 98.4ft
✓ Ultra 265 / H.265 / H.264 / MJPEG
✓ Dual stream support
✓ Third-party recorder integration flexibility
✓ ONVIF Profile S / G / T, API, and SDK support
✓ Built-in microphone and built-in speaker
✓ MicroSD card support up to 512GB
✓ DC 12V and PoE power support
✓ IP67 weather protection
✓ 3-axis adjustment

Best Applications

Storefronts
Building Entrances
Parking Areas
Car Wash Sites
Warehouse Areas
Public-Sector Projects

Product Highlights

The IPC3614SR-ADF28KMC-DL-H supports multiple main stream and sub stream resolution options. This is helpful for third-party recorder integration because some non-UNV recorders may not support the camera’s full 4MP output, full frame rate, codec, ONVIF profile, audio features, dual-light behavior, or stream profile. If a third-party recorder cannot display or record the full-resolution stream properly, the camera may need to be adjusted to a lower supported resolution, FPS, compression format, or stream setting for better compatibility.

Model IPC3614SR-ADF28KMC-DL-H
Camera Type 4MP ColorHunter Dual-Light Fixed Eyeball Network Camera
NDAA Compliance NDAA compliant / NDAA supported. Please verify current manufacturer documentation before ordering for government, public-sector, or compliance-sensitive projects.
Image Sensor 1/3.0" CMOS
Resolution 4MP
Main Stream 4MP 2688 × 1520, max 30fps
4MP 2560 × 1440, max 25fps
3MP 2304 × 1296, max 30fps
1080P 1920 × 1080, max 30fps
720P 1280 × 720, max 30fps
Sub Stream 720P 1280 × 720, max 30fps
D1 720 × 576, max 30fps
640 × 360, max 30fps
Third-Party Recorder Integration Third-party recorder compatibility is commonly affected by ONVIF profile support, firmware version, codec support, camera resolution, frame rate, audio support, smart light behavior, and stream profile settings. If a third-party recorder cannot display or record the full 4MP stream properly, the camera may need to be adjusted to a lower supported resolution, FPS, compression format, or stream setting.
Compatible Integration ONVIF Profile S / Profile G / Profile T, API, SDK
Video Compression Ultra 265 / H.265 / H.264 / MJPEG
Video Bit Rate 128 Kbps to 16 Mbps
Video Stream Dual Streams
Low-Light / Color Imaging ColorHunter with dual-light illumination
Minimum Illumination Color: 0.003 Lux, 0 Lux with light
Wide Dynamic Range 120dB True WDR
Lens 2.8mm Fixed Lens, F1.6
Field of View Horizontal 97.0°
Vertical 52.2°
Diagonal 107.5°
DORI Distance Detect: 63.0m / 206.7ft
Observe: 25.2m / 82.7ft
Recognize: 12.6m / 41.3ft
Identify: 6.3m / 20.7ft
Supplemental Light Dual Light: Smart IR + Warm Light
IR Distance Smart IR up to 30m / 98.4ft
Warm Light Distance Warm Light up to 30m / 98.4ft
Audio Built-In Microphone and Built-In Speaker; Two-Way Audio Support
Audio Compression G.711U / G.711A, 64 Kbps
Smart / Event Features Motion Detection, Ultra Motion Detection, Tampering Alarm, Audio Detection, Cross Line Detection, Intrusion Detection
Storage MicroSD Card Support up to 512GB; ANR; NAS (NFS)
Network 1 × RJ45 10M/100M Base-TX Ethernet
Power DC 12V ±25% / PoE IEEE 802.3af, max 8.0W
Dimensions Ø110.5mm × 97.2mm / Ø4.4" × 3.8"
Weight 0.32kg / 0.71lb
Material Metal
Adjustment Angle Pan 0°–360°, Tilt 0°–80°, Rotate 0°–360°
Protection IP67 Weather Rated

Installation Tip

For best image quality and recorder compatibility, confirm camera angle, IR reflection, warm light behavior, audio recording rules, speaker behavior, PoE power, stream resolution, FPS, codec, ONVIF profile support, NDAA documentation, storage settings, and recorder compatibility during setup. If the recorder is a third-party model, test both the main stream and sub stream before final installation.

Note: Specifications are subject to change without notice. NDAA status, features, MicroSD card support, audio functions, speaker functions, two-way audio behavior, image performance, stream resolution, frame rate, codec support, IR distance, warm light distance, PoE behavior, ONVIF profile support, third-party recorder compatibility, ColorHunter behavior, dual-light behavior, and overall system performance may vary depending on firmware version, recorder model, ONVIF implementation, installation environment, lighting conditions, network setup, camera settings, stream profile, and system configuration. Please always double-check the manufacturer’s official specifications, NDAA documentation, and recorder compatibility before ordering.

Important product information: Specifications are subject to change without notice. Features, storage support, audio functions, image performance, PoE behavior, compatibility and overall system performance may vary depending on firmware, recorder model, installation environment, network setup and system configuration. NVRs do not include hard drives unless explicitly stated.
