Uniview
Model: IPC2K24SE-ADF40KMC-WL-I0
In stock
Pre-order — ships when inventory arrives. Contact us for the current lead time.
Apply for dealer pricing For approved dealers. Pricing and terms vary by product and quantity.
The UNV IPC2K24SE-ADF40KMC-WL-I0 stitches two camera views into a wide 4MP image. Its nominal 160° horizontal coverage suits a broad frontage without using a moving PTZ.
The wide output uses a different aspect ratio from a conventional 4MP camera. Check that the recorder accepts 3840 × 1080 and displays it correctly.
The listed maximum is 25fps with human detection off and 20fps with it enabled. Configure detection, recording and two-way audio together for the intended system.
| Low-Light Processing | ColorHunter |
|---|---|
| Model | IPC2K24SE-ADF40KMC-WL-I0 |
| Camera Type | 4MP ColorHunter OmniView Dual-Lens Bullet Camera |
| Image Sensor | Dual 1/2.9" Progressive Scan CMOS |
| Maximum Resolution | 3840 × 1080 |
| Frame Rate | 25fps (Human Detection Off) / 20fps (Human Detection On) |
| Lens | Dual 4.0mm Fixed Lens |
| Lens Aperture | F1.0 |
| Horizontal Field of View | 160° ±10° |
| Vertical Field of View | 43.2° |
| Diagonal Field of View | 180.1° ±10° |
| Minimum Illumination | 0.0005 Lux (Color, F1.0) |
| Night Vision | 30m Warm White LED |
| Wide Dynamic Range | DWDR |
| Video Compression | Ultra 265, H.265, H.264, MJPEG |
| AI Analytics | Human Body Detection |
| Built-in Audio | Dual Microphones + Speaker (Two-Way Audio) |
| Audio I/O | 1 Input / 1 Output |
| Alarm I/O | 1 Input / 1 Output |
| Edge Storage | MicroSD Card up to 512GB |
| Network Interface | RJ45 10/100 Mbps Ethernet |
| Power Supply | 12V DC ±25% / PoE IEEE802.3af |
| Maximum Power Consumption | 6.5W |
| Protection Rating | IP67 |
| Operating Temperature | -30°C to 60°C (-22°F to 140°F) |
Nominal viewing angle has the manufacturer’s stated tolerance. Confirm panoramic resolution, audio and event support before selecting an NVR.
Flexible deployment
View a compatible camera with UniEase. Local microSD recording is available on supported models.
Bring cameras together for centralized recording and viewing. Use UniEase for supported remote access.
Illustrative setup. Storage, network connections and app features depend on the camera, recorder and firmware. Internet access is required for remote viewing.
Need help matching this product to your project? Ask NSI
Choose accessories for your setup. Sold separately.
Live view, playback and alerts for supported UNV cameras and recorders.
Manage supported cameras and recorders with the EZStation desktop CMS.
Discover and configure supported devices on your local network.
Features and compatibility depend on the device model, firmware and software version. Check UniEase device compatibility
